Three Pieces Ball Valves Series
    1000 PSIG : V-558 , V-258 , V-205T , V-205W , V-205S
                           V-005C , V-005E , V-005K , V-005G
    2000 PSIG : V-255 , MK-855EB , MK-855TC

Three Pieces Ball Valves Series : MK-855EB


 Specifications :
1/2" ~ 2" (NW 15 ~ NW 50)
Blow-out-proof stem & Anti-static Design
Body : ASTM A-351 GR.CF8M (DIN 1.4408)
Ball : SS 316
Stem : SS 316
Seat : PTFE

End Connections :

 Tubing End
Working Pressure : 1/2"~1" 2000 psi(CWP)
  1-1/4"~2" 1500 psi(CWP)
Temperature Range : -60 to 450oF(-40 ~ 218oC)
Options : Cavity filled PTFE Seat
