| Three
Piece Ball Valves Series : V-255 1/4"
~ 2" |
 |
Feature :
V-255 :Full Port 1/2" ~ 2" (NW15 ~ NW50)
V-255A:Reduced Port 1/2" ~ 2" (NW15 ~ NW50)
Blow-out-proof stem & anti-static design.
Handle with locking device.
ISO 5211 Mounting Flange.
Bdoy:ASTM A351 Gr. CF8M (DIN 1.4408).
Ball:SS 316.
Stem:SS 316.
Seat:PTFE+15%GF.
|
| |
|
| |
|
 |
Design Specifications : ANSI B16.34
Class 600
| End Connections : |
Butt Weld End. |
|
Socket Weld End. |
|
Threaded End. |
| Working Pressure: |
1/4" ~ 1" 2000 psi WOG. |
| |
1-1/4" ~ 2" 1500 psi WOG. |
Temperature range : -60 to 450 oF(-40o
to 218oC). |
| |
|
 |
 |
| |
|
|
|
|
|
